Hello, everyone in the community. I currently want to do a flexible model of corn leaves ( in line with the actual physical behavior, such as bending ) in EDEM, as if hypermesh and EDEM co-simulation can be done. Do you have this information ?
Hi,
You could use either the bonding v2 or fibres bonding model for this. I don't have any specific material properties to share but you could set it up using the meta particles and one of the bond models.
https://help.altair.com/edem/topics/creator_tree_physics/fibers_bonding_model_c.htm
https://help.altair.com/edem/topics/creator_tree_physics/the_bonding_v2_model_r.htm
The fibers bonding model is more designed for stems (sphero-cylinders) but would be a good option to look at for leaves, in the community link. With both models you can create some complex flexible shapes:
Regards
Stephen
