New Timing Axis in PSIM v12 | Waveform Analysis

Sarah Lynch_20319

This tutorial video introduces the new timing axis which allows users to quickly analyze the relative timing of waveforms. To highlight this feature the gating pulses of a 10-level MMC 3-phase inverter are used. The timing of 10 gating pulses is quickly and easily analyzed in this multi-level inverter.

https://www.youtube.com/watch?v=6YCXbV0pwGE
