How to use motion solve to simulate the harmonic drive

永瀚 杜

I am currently using motion solve to simulate the motion of the harmonic reducer.

At present, the external rigid wheel is fixed with a fixed joint, and the wave generator is disassembled into two parts, because the process of the wave generator supporting the flexible wheel is to use translation Joints are used to simulate the stretching process.

The current problem is that when the rigid spline and the flexible spline are in contact, the rigid spline cannot generate contact stress, and when the rigid spline and the flexible spline are in contact, the teeth will penetrate.

I would like to ask everyone how to solve this problem? Please help me to solve the problem again, thank you!
