Level 2 IGBT model

Sarah Lynch_20319
Sarah Lynch_20319
Altair Employee
edited January 2023 in Altair HyperWorks

This tutorial covers the use of a Level 2 IGBT model for PSIM. The level 2 model is not a SPICE model and is not a piece-wise approximation. The level 2 model is derived from datasheet parameters and gives a more realistic look at gate drive and switching transitions. It is easier to use and is compatible with digital and motor drive simulations.


https://www.youtube.com/watch?v=FISMo0iFCnk
