Variable Time Step Intro

Sarah Lynch_20319

This tutorial video introduces the new variable time step that is available with PSIM version 12 and higher. The video highlights how the variable timestep allows for a faster simulation without reducing the simulation fidelity. The smaller step size is only used at the switch transition points while a coarse step is used between transitions.

https://www.youtube.com/watch?v=agzcuhM2F-c
