Hi,
I would like to model a cable. After doing a VNA measurement I receive a cable's S11 parameter or impedance vs frequency plot. I want to mimic this value in a psim simulation. How can I give the frequency vs impedance profile as an input to my PSIM simulation to perfectly give a cable behavior in the simulation?
Help will be appreciated.
AA
