Inverter Design with Average Current and Voltage Loop Control

Sarah Lynch_20319

In this video, PSIM & SmartCtrl are used to implement an inner average current mode control loop and an outer voltage loop. PSIM is used to size the energy storage components, generate frequency response (AC sweep), & to verify the stability. SmartCtrl is used to generate PI controllers for the inner loop and outer loop.


https://www.youtube.com/watch?v=25c8_trrmSo

Other related resources:

• 3 Phase Gridlink Inverter with dq Control Design Video
• AC Sweep With Digital Delay Using Multi-Sine AC Sweep
• Introduction to PSIM Multi-Sine AC Sweep
