PSIM AC Sweep – Ultimate Flexibility

Sarah Lynch_20319

AC sweeps or frequency responses in PSIM make use of switching models, so there is no need to determine the average model. You can do a sweep on simple dc-dc converters, peak current mode control, digital control, motor models, phase shift converters, 3-phase inverters, loop gain response, and input/output impedance. Any topology or frequency response is possible.

https://www.youtube.com/watch?v=wZO4d86VtIs
