Co-simulation of Simulink and PSIM with SimCoupler

SarahLynch_2022

Set up a co-simulation between Matlab/Simulink and PSIM using PSIM's SimCoupler module. This video covers the setup process so that you can link a PSIM simulation with Simulink:

- Determine the signals to pass between the two programs,

- Setup waveforms to analyze in post-processing

- Setup variables that can be defined in Simulink and passed to PSIM

- Basic troubleshooting steps


https://www.youtube.com/watch?v=B5f1pbWdKCg
